Matek AP Periph GNSS M10-L4-3100 GPS Module

The MATEKSYS AP Periph GNSS, M10-L4-3100 GPS is equipped with AP_Periph L431 CAN node, MAX-M10S, RM3100, SPL06-001, DroneCAN protocol & UART_MSP, and many other cool specs that make this GPS a winner in the wing game!



Features

  • M10-L4-3100 is based on ArudPilots’ AP_Periph firmware, It is a GNSS+COMPASS+BAROMETER peripheral with CAN/DroneCAN and UART/MSP interfaces.
  • M10-L4-3100 uses multi-constellation GNSS powered by u-Blox MAX-M10S, MAX-M10S is a concurrent GNSS receiver that can receive and track multiple GNSS systems. Owing to the multi-band RF front-end architecture all four major GNSS constellations, GPS, Galileo, GLONASS, and BeiDou can be received concurrently.
  • M10-L4-3100 integrates an industrial-grade compass PNI RM3100 which provides high resolution, low power consumption, no hysteresis, large dynamic range, and high sampling rates.



Specifications

  • Firmware: ArduPilot AP_Periph: MatekL431-Periph
  • GNSS u-blox MAX-M10S (GPS, GLONASS, Galileo, and BeiDou)
  • Magnetic Compass RM3100
  • Barometer SPL06-001
  • Patch GNSS Antenna 25*25*4mm
  • MCU STM32L431RCT6
  • UART3, onboard MAX-M10S
  • UART2(TX2 RX2), MSP Protocol
  • CAN, DroneCAN Protocol
  • I2C JST-GH connector for external AirSpeed sensor
  • LED Indicators:
    • CAN Bootloader LED - Blue
      • Slow blinking, working
      • Fast blinking, Booting
    • GNSS PPS LED, Green
      • Blinking(1Hz) when GNSS has 3D fixed
      • Solid on after powering on
      • 3.3V LED, Red
  • Input voltage range: 4.5~5.3V (5V pad/pin)
  • Power consumption: 60mA
  • Operating Temperatures: -20~80 °C
  • 36mm*36mm*12mm
  • 16g



IMPORTANT NOTES

  • On M10-F4-3100, The 3 magnetic coils have little solder paste to avoid the excess to “tilt” them, resulting in some reading inaccuracies of the compass. Any strong impacts will definitely separate them, especially the “tall coil” Sen-Z-f.  Please use this precision module with care.
  • The default configuration on MAX-M10S with u-Blox FW5.1 is concurrent reception of GPS, Galileo, and BeiDou B1I with QZSS and SBAS enabled.  GLONASS is disabled by default.
  • Beidou B1I (1561.098 MHz) and GLONASS can’t be enabled at the same time.  Beidou B1C (1575.42 MHz) and GLONASS can be enabled at the same time. Flight controller firmware(INAV, Betaflight, ArduPilot) doesn’t support enabling Beidou B1C for now.
  • With GPS, Galileo, and BeiDou B1I with QZSS and SBAS enabled, MAX-M10s can receive more than 30 Sats with HDOP down to 0.55.
  • Starting with u-Blox GNSS FW3.01, the time pulse is aligned with UTC time and that time is set valid only after the leap second is downloaded. That could take up to 12.5 min. Probably PPS LED will not blink immediately after GPS has 3D fixed.



Links



Includes

  • 1x M10-L4-3100
  • 2x JST-GH-4P to JST-GH-4P 20cm silicon wire
  • Mounting base (1x PCB plate, 4x silicon grommets, 4x Nylon standoffs M3x7, 4x Nylon screws M3*8)
