TransTEC Laser S RC FPV Drone Frame Kit
The Laser S FPV Drone is a one of a kind Hybrid FPV Frame. This Frame has been designed with racers in mind and offers the best of both worlds on Race day. The Laser S offers so many features, but a key feature is that it allows FPV Pilots to be able to run a 20x20 or 30x30 stack. The carbon fiber has chamfered edges which gives it a nice sleek look. If the features below aren't enough it is a preferred racing frame by Team Canada Pilots!
Features:
- Full 3K imported premium quality and structurally rigid carbon fiber
- All Carbon Fiber with chamfered and round edge
- All Carbon plates cut with TransTEC Soft Coating Crafts
- super durable 6mm arms with quick switch
- 3mm Hybrid bottom plate with soft mount hole
- 2.5mm thickness ultra light roof plate
- 2mm thickness top plate ensures stable arms
- Aerospace application TransTEC 7075Alu column for incredibly solid
- High precise 3D print camera holder and new design to protect your cam
- Two alternative antennae fixed way for more convenience installation
- 304 stainless steel custom insert nut for a more stable frame
- YFS first-class 12.9 screws to secure the whole frame
- 20x20mm and 30x30mm FC mount hole
- Large internal space possible for 3 board FC stack
- Allowing to fit the micro camera.
- Wheelbase 224mm (Suitable 6 inch Type)
- TransTEC Damping System, unique design soft rubber ring and custom 7075 limit screws, let the rubber remains a same force
Specifications:
- Size - 224mm
- Weight - 82g
- Material - 3K Carbon Fiber With Soft Coating
- Arm Thickness - 6mm
- Bottom Plate - 3mm
- Type - Hybrid
Package Includes:
- 4 x 6mm removable Arms
- 1 x 3mm Bottom plate
- 2 x 2mm Top plates
- 1 x 2.5mm Roof plate
- M3x12 * 4
- M3x16 * 4
- M2.5x8 * 2
- M2.5 Metal Nut * 2
- M3 Metal Nut * 4
- M3 Insert Nut * 4
- M3x8 Countersunk screws * 4
- M3 7075 Limit Red screws * 4
- TPU camera mount * 1
- TPU SMA antenna mount * 1
- TPU lollipop antenna mount * 1Battery strap 2pcs
- Battery pad 1pcs
