WalkSnail Avatar GT Kit HD Pro Micro Camera Dual Antenna

  • $329.99
(Ex GST: $299.99)



WalkSnail Avatar GT Kit HD Pro Micro Camera Dual Antenna

Specification


Camera
Model Avatar HD Pro Camera
Image Sensor 1/1.8-Inch Sony Starvis  sensor
Resolution 1080P/60fps; 1080P/100fps; 720P/120fps; 720P/60fps;
Ratio 16/9; 4/3
Lens 8Mp
FOV 160°
Aperture F1.6
Shutter Rolling shutter
Min.Illumination 0.00001Lux
Weight 9.5g
Dimensions 19*19*24mm
Coaxial Cable 140mm
Gyroflow supported

VTX


Model Avatar GT
Communication Frequency 5.725-5.850 GHz
Transmitter Power (EIRP) FCC: <30dBm, MAX:33dBm ; CE: <14dBm;
SRRC: <20dBm; MIC: <25dBm
I/O Interface Micro SD card slot; JST1.0*4(power cable)
Supported SD Cards Micro SD (up to 256 GB)
Mounting Holes 25.5*25.5mm; 20*20mm
Dimensions 34*34*20mm
Recording 1080p/720p
Weight 41.6g (Antenna included)
Operating Temperature -10-40℃
Channels 8
Wide Power Input 11.1V-25.2V
Supported FC System Betaflight; Inav; Fettec; Kiss; ArduPilot
OSD Canvas mode
Latency Average delay 22ms
Antenna 2(IPEX)

Note: Check area for risk of use before use.

Packing List

  • 1x Walksnail Avatar GT KIT
  • 1x Quick Guide
  • 2x M2*4mm screws
  • 2x M2*5mm screws
  • 2x M2*6mm screws
  • 2x M2*5*0.5mm spacer
  • 2x SD card stickers
  • 1x 4pin power cord

2W (Max) Long Range
11.1V-25.2V 1080P 100fps
Dual Antennas High Frame Starlight
Micro SD Card Slot Compatible Moonlight Camera(DVR 4K)



Bullet Points

Avatar GT significantly enhances signal transmission distance, meeting various flight requirements, and can reach up to 2W power within legal and regulatory limits, ensuring uninterrupted flight exploration and enhancing your FPV experience.
The Avatar GT features a top-mounted heatsink design, effectively dissipating heat to maintain optimal performance even during extended operation.
The Avatar GT is equipped with a Micro SD card slot, supporting up to 256GB of storage capacity, enabling uninterrupted recording of HD flight videos in either 1080p or 720p resolution.
The Avatar GT boasts an internal ceramic antenna that optimizes performance during low-power mode, minimizing power consumption and heat generation.
The Walksnail Avatar GT KIT now features improved resistance to GPS interference, ensuring a more stable and reliable flight experience even in challenging environments.
Avatar GT comes with a Pro camera, equipped with a 1/1.8-inch Sony Starvis II sensor, providing excellent night vision capabilities with clarity comparable to daytime.
The camera supports Gyroflow, take you smooth and stable video quality.
It supports high frame rate and standard frame rate at the same time. Under high frame rate, the average delay is 22ms.
Designed to carry dual antennas to achieve more stable and powerful signals. The quality of the antenna is upgraded, and the working performance of the whole frequency band is more stable.
